Ice maker ICE TECH 50014

The ICE TECH SC5TN SPLIT is an industrial ice maker, article 50014, designed for split installations. This unit produces flat ice flakes with an adjustable thickness ranging from 1.5 mm to 3 mm.

An ice maker of this type operates by freezing water onto a chilled surface within a cylinder. In this model, the static cylinder design, which avoids rotating joints, facilitates the continuous formation of ice. Water is introduced and circulated over the cold cylinder walls, where it freezes into thin sheets. As the ice layer reaches a specific thickness, it is harvested, often by a mechanism that breaks the bond between the ice and the cylinder. The resulting ice flakes are then collected. This method allows for consistent ice production.

The SC5TN SPLIT features an electronic stop system to manage the ice production cycle. It includes an electrical control panel for operation and monitoring. The ice maker is powered by a direct-drive gear motor, which is connected to the ice harvesting mechanism. A magnetic water pump is used to circulate water within the system. The unit is constructed with a stainless steel base for stability and hygiene.

Safety and operational features include a low water level safety device to prevent dry running, and sensors for monitoring water level, motor overload, and full bin detection. The ice exit has a diameter of 480 mm.

The power requirement for this ice maker is 27.5 kW at 230 V and 1 phase. Its physical dimensions are 1850 mm in length, 1150 mm in width, and 1300 mm in height, with a total weight of 800 kg.

This unit requires a professional refrigeration connection and the use of a KVP valve for proper operation. Cleaning and upkeep would involve regular checks of the water system, sensors, and the ice harvesting components, following manufacturer guidelines for stainless steel surfaces and internal mechanisms.

This model is specifically listed in the catalogue for ice generator split installations.
