Ice flake machine ICE TECH 50002

The ICE TECH SC1TN COMPACT is a professional ice maker designed for continuous, high-volume ice production. This unit is capable of producing 1000 kg of ice within a 24-hour period.

An ice maker operates by freezing water onto a chilled surface, which is then harvested as ice. In this model, water is supplied to a freezing cylinder where it comes into contact with a rotating evaporator. As the water freezes, it forms a layer of ice on the cylinder. The ice is then scraped off by a blade and falls into a storage area. This process results in cold and dry flat flake ice, with an adjustable thickness ranging from 1.5 mm to 3 mm.

The SC Compact version is a fully autonomous solution, incorporating a built-in compressor and condenser for self-contained operation. The unit is managed by an electronic control system accessed via an electrical control panel. For operation, it features a direct-drive gear motor and a magnetic water pump. Safety is enhanced with a low water level system.

Construction includes a stainless steel base. The machine is fitted with sensors to monitor water level, motor overload, and to control when the ice bin is full.

Specifications include a production capacity of 1000 kg/24h, power consumption of 5.5 kW, voltage of 400 V, and 3 phases. Dimensions are 1360 mm long, 1050 mm wide, and 1000 mm high, with a weight of 249 kg. The ice exit diameter is 480 mm.

This ice maker is suitable for fish and seafood processing, supermarkets and food display counters, industrial production processes, cold rooms and warehouses, restaurants and professional kitchens, and laboratories and medical institutions.

Cleaning and upkeep would involve regular descaling and sanitisation of the water system and ice contact surfaces, as well as checking the sensors and motor for proper function. The stainless steel base facilitates cleaning.
