Ice flake machine ICE TECH SC10TN

The ICE TECH SC10TN COMPACT is a professional ice maker designed for high-volume ice production. This unit produces cold and dry flat flake ice, with an adjustable thickness ranging from 1.5 mm to 3 mm.

The operating principle of an ice maker involves a refrigeration system that cools a metal surface. Water comes into contact with this cold surface, freezing into ice. For flake ice makers, this typically involves a rotating cylinder or auger against which water flows and freezes. The ice is then scraped or broken off the surface and collected. The SC Compact version offers a fully autonomous solution for professional environments.

This ice maker is equipped with an electronic control system and an electrical control panel for operation. It features a direct-drive gear motor for power transmission, a magnetic water pump to circulate water, and a low water level safety system to prevent operation without sufficient water. The unit includes sensors for monitoring water level, motor overload, and full bin control, ensuring safe and operation.

The ice exit has a diameter of 480 mm. The construction includes a stainless steel base.

Key specifications for the ICE TECH SC10TN include a production capacity of 10000 kg per 24 hours. The unit requires a power supply of 400 V, 3-phase, with a power consumption of 55 kW. Its dimensions are 6200 mm in length, 1400 mm in width, and 1940 mm in height. The total weight of the unit is 1950 kg.

This ice maker is suitable for various applications including fish and seafood processing, supermarkets and food display counters, industrial production processes, cold rooms and warehouses, restaurants and professional kitchens, and laboratories and medical institutions.
