Technical data
| Attributes | |
| ARTICLE | LCT750F/BLACK |
| POWER | 0.242 kW |
| SIZE L/W/H | 700/ 560/ 670 mm |
| VOLTAGE | 220-240/ 50Hz |
| Temperature | +2/ +8 °C |
| VOLUME | 67 l |
| WEIGHT | 65 kg |
| SHELVES | 2 wires shelves chrome |
| PRODUCT COLOR | grey |
| NOTES | 4 adjustable feet |
Temperature mode +2/ +8 °C
A refrigerated display counter keeps chilled food visible and accessible while maintaining a steady low temperature. A compressor circulates refrigerant through a coil behind the unit, pulling heat from the interior. A fan then distributes the cooled air evenly across the shelves, ensuring every item stays within the set temperature range. The double-glazed glass front and sliding rear doors minimise cold-air loss while allowing customers to view the contents without opening the cabinet, reducing energy use and temperature fluctuations.
To use the LCT750F/BLACK, place the counter on a level worktop or floor. Adjust the four feet until the unit is stable and level. Plug the appliance into a 220–240 V, 50 Hz supply. Load the two chrome wire shelves with chilled products, ensuring airflow is not blocked. Set the desired temperature between +2 °C and +8 °C using the control panel. The LED interior light will illuminate automatically when the doors are opened or when the unit is powered on, making items clearly visible. Slide the rear glass doors to restock or rearrange the display.
The counter is constructed from stainless steel, providing a durable and easy-to-clean surface. The flat top allows for additional storage or preparation space in a busy kitchen. The double-glazed glass doors and sliding rear access improve visibility and accessibility while maintaining insulation. Ventilated cooling ensures consistent temperatures across the 67 L interior, preventing hot spots and preserving food quality.
The control panel allows adjustment of the internal temperature within the +2 °C to +8 °C range, suitable for displaying chilled foods such as desserts, salads, or pre-packaged meals. The 0.242 kW power rating indicates the load the unit places on the electrical supply, which should be considered when planning kitchen circuits. The 65 kg weight means the counter can be moved with a trolley but is stable once positioned. The 700 mm width fits standard worktop depths, making it suitable for most countertop installations.
Cleaning involves wiping the stainless steel exterior and interior with a damp cloth and mild detergent. The chrome wire shelves can be removed for thorough cleaning. The LED light does not require maintenance beyond occasional dusting. The adjustable feet should be checked periodically to ensure the unit remains level, preventing strain on the cooling system.
The LCT750F/BLACK is available in grey with a black trim. It is categorised under refrigerated display counters in the TEFCOLD professional catering equipment range.
