Counter refrigerator table without drawers FAGOR 19089594

This pass-through refrigeration counter allows staff to access chilled ingredients from both sides of the worktop. An internal fan circulates cold air, removing heat from stored items and maintaining an even temperature throughout the unit. The refrigeration system operates until the set temperature is reached, then pauses until further cooling is needed, balancing energy efficiency with stable storage conditions.

To operate, open the doors on either side and place GN1/1 trays onto the adjustable guides or the fixed shelf. The electronic control panel enables temperature settings between 0 °C and +8 °C, with a digital display showing the current reading. Once the doors are closed, the fan and compressor activate automatically, circulating cold air until the interior reaches the desired temperature. The off-cycle defrost system temporarily stops the compressor, allowing frost to melt without additional heaters or timers before cooling resumes.

Constructed from stainless steel inside and out, including the worktop, the counter is easy to clean and resistant to corrosion. A 50 mm layer of insulation minimises cold loss and helps maintain consistent temperatures. Each door features a removable magnetic gasket to seal the cabinet and simplify hygiene maintenance. The interior includes one fixed GN1/1 shelf and two sets of height-adjustable tray slides per door, offering flexible storage for varying tray heights. The slides are epoxy-coated for durability and support up to 40 kg per shelf. Adjustable legs allow the unit to be raised or lowered between 130 mm and 200 mm to match existing work surfaces or uneven floors.

With a 274 L capacity, the counter accommodates multiple GN1/1 trays, while its 1342 mm width suits standard kitchen layouts. The 110 kg weight requires two people for safe movement. The 0.361 kW power rating ensures compatibility with a standard single-phase circuit. The refrigerant R600a is a low-impact hydrocarbon, and an R290 version is available for alternative power supplies.

Cleaning involves wiping stainless steel surfaces, removing and washing the magnetic gaskets, and sliding out the adjustable guides for thorough cleaning. The fan and compressor need no daily maintenance beyond ensuring air vents remain unobstructed. The counter meets climate class 4 standards, operating reliably in ambient temperatures up to the specified maximum.

The CCPC-2G/C model is designed for pass-through use, featuring doors on both sides. Each door includes one GN1/1 shelf and two sets of adjustable guides, and the unit is compatible with standard gastronorm trays.
