Refrigerated display cabinet SCANDOMESTIC 26311010000BB131HBA

A ventilated display cooler keeps bottled and canned drinks chilled while showing them to customers through a clear glass door. Cold air is drawn across the evaporator coil at the back of the cabinet and then pushed by a fan through vents at the top and bottom of the interior. The constant air flow keeps every shelf at the same temperature, so the first bottle on the top shelf is as cold as the last can on the bottom. Because the air is dry, labels stay legible and condensation does not collect on the glass, so the display stays clear and professional.

To load the cooler, the operator opens the glass door, places bottles or cans on the chrome mesh shelves, and closes the door. The automatic closer ensures the door seals without being forced. The electronic control panel on the front sets the temperature between 0 and 10 °C; the external digital display shows the current reading. LED lighting inside switches on when the door opens, illuminating the drinks without adding heat. When the unit is not in use, the lock secures the contents.

The cabinet is finished in black and measures 500 mm wide, 530 mm deep and 865 mm high, so it fits under most counters and bars. Two chrome shelves with a fine mesh support up to 30 kg each, allowing stable storage of bottles and cans of different sizes. Adjustable front feet level the unit on uneven floors. The heat exhaust is front-mounted, so the cooler can be built into a run of cupboards without blocking ventilation.

An 86 litre volume holds up to 48 bottles of 50 cl, 35 bottles of 33 cl, or 133 cans of 25 cl. The temperature range of 0 to 10 °C suits soft drinks, beers and mixers; it is not cold enough for dairy or fresh meat. The unit runs on 220–240 V, 50 Hz, the standard single-phase supply in British commercial kitchens. A weight of 38 kg allows two people to move it without a trolley.

Cleaning is done with the unit switched off and empty. The chrome shelves lift out for washing in warm water with mild detergent. The interior surfaces are wiped with a damp cloth; abrasive cleaners or scouring pads are not needed. The door seal should be checked regularly for cracks and cleaned to keep it flexible.

The model is the BB131HBA, part of the SCANDOMESTIC range of under-counter refrigeration. It is listed in the catalogue under display coolers for bars and self-service areas.
