Refrigerator FORCAR G-GNB600TN

A static refrigerated cabinet keeps perishable ingredients at safe holding temperatures without forced air currents that can dry out uncovered food. The cooling system circulates refrigerant through a static evaporator coil mounted inside the insulated cavity. As the refrigerant absorbs heat from the stored items, a small fan gently moves the air across the coil, ensuring an even temperature throughout the cabinet without creating the strong airflow of a fan-assisted unit. Condensation forms on the coil and drips into a collecting basin beneath, where it evaporates automatically, eliminating the need for manual drainage.

To use the cabinet, slide the three supplied GN2/1 grids into the pairs of runners at the desired shelf heights. Load ingredients onto the grids, close the self-closing door, and set the electronic controller to the required temperature between +2 °C and +8 °C. The internal air conveyor maintains the chosen temperature while the automatic defrost cycle prevents ice build-up on the coil. A drip tray beneath the coil collects any residual condensation, which evaporates over time.

The exterior is constructed from white epoxy-painted steel, while the interior liner is aluminium for corrosion resistance and easy cleaning. The door is fitted with a self-closing spring and can be reversed to suit the kitchen layout. Height-adjustable feet in stainless steel allow the cabinet to be levelled on uneven floors. A 60 mm layer of insulation minimises heat transfer, keeping energy consumption low.

The 507 L capacity provides ample space for GN2/1 gastronorm trays, while the 260 W power rating indicates a modest electrical load suitable for a standard 220–240 V single-phase circuit. The 155 kg weight requires two people to move the cabinet safely, and the 680 mm width and 800 mm depth determine the floor space it occupies. The internal dimensions of 560 x 653 x 1386 mm define the usable storage volume for trays and loose ingredients.

Cleaning involves wiping down the aluminium interior and epoxy-painted exterior with a mild detergent solution. The drip tray and collecting basin should be checked regularly to ensure condensation is evaporating properly. The three GN2/1 grids and pairs of slides can be removed for thorough cleaning.

The cabinet is supplied with three GN2/1 grids and three pairs of slides, and the door can be reversed to open from either side. The cooling gas used is R290, a hydrocarbon refrigerant with low environmental impact.
