Refrigerator FORCAR G-ERV400SS

The FORCAR Refrigirated cabinet ventilated Eco Line G-ERV400SS is a refrigerated cabinet designed for refrigerator applications. Its construction features a body finished in white epoxy-coated sheet metal, with an interior made from PS. The exterior rear and bottom panels are made from galvanised sheet metal, while the overall construction material is stainless steel.

This cabinet operates on a ventilated refrigeration principle. This system uses a fan to circulate cold air throughout the interior, ensuring consistent temperatures and rapid cooling. It incorporates automatic defrosting to prevent ice build-up and automatic condensate water removal, simplifying maintenance. The insulation thickness is 70 mm, contributing to its energy efficiency.

The sequence of use involves placing items inside the cabinet, which is equipped with 3 grids and 1 bottom grid for storage. The temperature is managed via an electronic control system, allowing for precise setting within its operating range. The door, which is reversible, provides access to the cabinet's interior.

The cabinet has a total capacity of 279 litres. Its external dimensions are 600 mm in width, 600 mm in depth, and 1860 mm in height. The internal dimensions measure 460 mm wide, 460 mm deep, and 1627 mm high. The unit operates at a power consumption of 0.21 kW and requires a 230 V power supply. It weighs 90 kg. The temperature range for operation is between 0 °C and 8 °C. The cooling gas used is R600a. The energy class is D.

Cleaning and upkeep would involve maintaining the interior surfaces and the grids. The single blind door is fitted with a handle for ease of use.
