Neutral module ROCAM 01900OMCRNQE

This external corner square module links self-service counters at a 45° angle, enabling efficient use of space while maintaining a continuous worktop. The design ensures trays and utensils transition smoothly between straight sections without interruption or misalignment. The angled face also directs customer flow naturally around the corner, keeping the worktop accessible from both sides.

Constructed with a stainless-steel frame, the module supports the weight of adjacent counters and any items placed on them. Adjustable feet beneath the frame allow for levelling on uneven floors and provide clearance from spills. A plinth can be added to hide the feet, creating a neat appearance at the base. The frame is covered with panels that match the Omnia range, available in multiple finishes for a consistent look across the entire setup.

Installation is straightforward. Position the module at the desired corner, adjust the feet to the correct height, and secure the adjoining straight sections to the module's connection points. Once levelled and fastened, the chosen panels are easily attached. The fixed 45° angle requires no further adjustment, allowing the operator to proceed with arranging trays, cutlery, or condiments on the straight sections.

The module measures 747 mm along each face and 910 mm in height, fitting standard worktop heights and ensuring sufficient clearance for trays to slide across the corner without obstruction. The empty module's weight ensures stability, while the stainless-steel structure evenly distributes the load from adjacent counters and items.

Cleaning is simple. Panels can be removed for individual cleaning—laminated wood panels with a damp cloth and mild detergent, and stainless-steel or powder-coated panels with non-abrasive cleaners. The adjustable feet and plinth can be lifted or removed for access to the floor beneath, facilitating thorough cleaning.

A variety of colours is available, including silver, rose, saffron, lime, sky, ocean, ivy, sage, cappuccino, clay, grey, niagara, veined white, white sand, birch, grey fog, elm, walnut, wenge, anthracite, veined black, pure white, aluminium, and matte black. Four finishes are offered: laminated wood, stainless steel, powder-coated steel, and over-panelled laminated wood, each providing a distinct aesthetic.

Designed specifically for the Omnia AQ range, this module connects only to Omnia AQ straight sections and is incompatible with standard Omnia A modules unless castors are excluded.
