Technical data
| Attributes | |
| ARTICLE | G-HAV91 |
| POWER | 180 W |
| SIZE L/W/H | 910 x 510 x 550(h) mm (565 x 420 x 460(h) mm Int.) |
| VOLTAGE | 220-240V (50 Hz) |
| Temperature | +2°C / +8°C |
| WEIGHT | 70kg |
| CAPACITY | 110 L |
| NOTES | 1 grid 390 x 552 mm TYPE OF COOLING GAS R600a Delivery time ~ 2 weeks |
+2°C / +8°C Cold display with 1 grid. Delivery time ~ 2 weeks
A ventilated cold display cabinet keeps chilled food visible and accessible while maintaining a steady low temperature. The unit circulates cold air with a fan, pulling heat away from the interior and expelling it through a condenser. This forced-air method cools the entire cabinet evenly, preventing warm spots that could spoil food. The refrigeration cycle runs on R600a gas, which absorbs heat as it evaporates inside the cabinet and releases it outside when compressed. Because the air is constantly moving, the cabinet recovers quickly after the doors are opened, keeping the set temperature without overworking the compressor. To use the G-HAV91, plug it into a 220-240 V supply and set the electronic control to the desired temperature between +2 °C and +8 °C. The cabinet cools automatically, and the LED interior light switches on to illuminate the contents. The single grid supplied measures 390 mm by 552 mm and fits inside the 565 mm by 420 mm work space. Doors slide on runners, allowing quick access without taking up floor space in front of the unit. An automatic defrost cycle melts any ice build-up, and the resulting water evaporates without manual intervention. The exterior is made of stainless steel AISI 430, chosen for its resistance to corrosion and ease of cleaning. Double glazing insulates the cabinet, reducing condensation on the glass and cutting energy use. The 180 W power rating reflects the load on the electrical circuit, while the 70 kg weight indicates the unit is designed to be moved with a trolley or two people. The 910 mm width and 510 mm depth fit into a standard worktop run, leaving space for adjacent equipment. The seamless stainless-steel finish resists kitchen splashes and wipes clean in seconds without trapping grease between seams. The grid lifts out for separate cleaning, and the sliding doors can be removed from their runners if deeper access is needed. The automatic defrost and water evaporation systems eliminate the need to empty trays or scrape ice. The G-HAV91 is a single model with no variants. It is placed in the catalogue under professional refrigeration, specifically cold display cabinets for front-of-house use.
