GN 1/1 pan trolley Novameta BHS-VTGZ16-38-53-173

A mobile rack organises up to sixteen full-size gastronorm trays in a single vertical stack, keeping prepared ingredients, plated dishes or chilled components within arm's reach of the worktop or pass.

The trolley's shelves are spaced to accept GN1/1 trays without tilting or jamming. Gravity holds each tray flat while the unit is wheeled between stations; no latches or clips are needed. The open frame allows air to circulate freely around the trays, so chilled or hot items stay at serving temperature longer than they would inside a closed cupboard.

To use the trolley, the operator slides each GN1/1 tray onto a shelf, starting at the bottom. The shelves are fixed, so loading order determines which tray is accessed first. Once loaded, the trolley is pushed to the required station—grill, plating area or cold counter—where trays are removed in the same sequence. The top shelf is left clear for temporary storage of utensils or lids during service.

Construction is stainless steel throughout, giving a smooth, corrosion-resistant surface that withstands daily wash-downs with hot water and detergent. The frame is welded for rigidity; no bolts or screws protrude to snag trays or clothing. Four swivel castors allow the trolley to be manoeuvred through narrow doorways and tight corners without tipping.

The overall footprint of 380 mm width and 530 mm depth fits between standard kitchen worktops and under most pass-through hatches. The 1732 mm height allows the trolley to be stored beneath overhead shelves or extraction canopies when not in use. Each shelf is positioned at a comfortable working height, so staff can load and unload without bending or stretching.

Cleaning is straightforward: trays are removed, the empty trolley is hosed down or wiped with a sanitising cloth, and the castors are checked for debris. The open design prevents dirt from accumulating in corners or behind panels.

The trolley is listed in the Novameta catalogue under mobile storage and transport equipment for professional kitchens.
