Deep fryer CASTA E7/SPE40BA

A countertop warmer that keeps batches of french fries hot, crisp and ready for service without overcooking or drying them out.

The unit holds a shallow vat of oil or fat above a sheathed heating element and below a ceramic heating plate. Heat rises from the bottom and radiates from the top, creating an even temperature field that surrounds the food. This dual-sided heating prevents cold spots and keeps every portion at serving temperature until the last order is plated. A perforated false bottom lifts the fries above any sediment, so they stay clear of excess oil and retain their texture.

To use, the operator slides the GN 1/1 stainless-steel container into the warmer tank, fills it with the prepared fries, and switches the unit on. The ceramic and sheathed elements warm the oil to the set point; once reached, the thermostat cycles the heat to maintain a steady temperature. The fries remain in the container until they are portioned out, and the container itself can be lifted out for cleaning or refilling without tools.

The entire cabinet is fabricated from AISI 430 stainless steel, chosen for its corrosion resistance and structural strength. The worktop is a 1.2 mm sheet of AISI 304 stainless steel, polished for hygiene and ease of wiping. Four sturdy legs raise the unit to a comfortable working height and allow air to circulate underneath.

A single rocker switch on the front panel controls power to both heating elements. When the switch is on, the elements draw 1 kW from a 230 V single-phase circuit, the standard supply for most British commercial kitchens.

The GN 1/1 capacity matches the standard gastronorm container size used across the industry, so the warmer integrates with existing storage and transport systems. The 400 mm width and 700 mm depth fit neatly on a standard worktop, while the 850 mm height keeps the serving level within easy reach of staff. The 1 kW power rating keeps the electrical load manageable, and the 230 V requirement means the unit can be plugged into a typical kitchen ring circuit without additional wiring.

After service, the GN 1/1 container is removed and washed separately. The warmer tank and false bottom are wiped down with a damp cloth and mild detergent; the ceramic and sheathed elements are cleaned only when cool and never submerged. The stainless-steel exterior and worktop are wiped daily to maintain hygiene.

The EASY 700 E7/SPE40BA is a single model with a neutral cabinet, designed for countertop placement in professional kitchens.
