Back bar refrigerator Novameta BHS-Z-FP0-G230-139/65/86

This Novameta backbar freezer counter, article BHS-Z-FP0-G230-139/65/86, provides refrigerated storage for bar environments.

The operating principle of a backbar freezer counter involves a refrigeration system that actively removes heat from the interior compartment to maintain low temperatures. A cooling unit, often a monoblock, circulates refrigerant through coils within the insulated cabinet. This process chills the air inside, preserving frozen goods. The insulation of the cabinet minimises heat transfer from the surroundings, allowing the refrigeration system to operate efficiently.

To use the freezer counter, items are placed within the two drawers or behind the single door. The drawers are fitted with 110% extending stainless steel telescopic rails, allowing them to be pulled out fully for easy access to contents. The interior also includes two self-levelling racks specifically designed for bordeaux wine bottles, ensuring they remain stable. The temperature can be set between -14 °C and -5 °C.

Construction includes stainless steel telescopic rails for the drawers. The cooling monoblock is designed for quick replacement, allowing for maintenance with minimal downtime.

The unit operates on a 230 V supply and draws 4.1 amps, with a power consumption of 0.506 kW. Its external dimensions are 1390 mm in length, 650 mm in width, and 860 mm in height. The internal volume is 260 litres.

Cleaning of the interior and exterior surfaces is recommended to maintain hygiene and performance. The removable cooling monoblock facilitates servicing.

This model is part of Novameta's range of bar equipment and is suitable for bar station applications.
