Technical data
| Attributes | |
| ARTICLE | 40202442 |
| POWER | 0.405kW (2.07 kWh/24h) |
| SIZE L/W/H | 1760/ 700 / 950 |
| VOLTAGE | 1x230V ~ 50Hz |
| Temperature | -2/+8°C |
| WEIGHT | 148kg |
| Model | TG7D/170A |
| SHELVES | Included:GN 1/1 shelf each door |
| CAPACITY | 271L |
| Refrigerant | R290 |
| NOTES | Energy efficiency class B; Climate class 5 |
This refrigerator table combines outstanding design with professional functionality — an ideal solution for any modern professional kitchen.
3 doors
Stainless steel work top with backsplash
Plug-in system
A refrigerated table keeps prepared ingredients chilled at safe temperatures while providing a work surface for plating and assembly. The system circulates cold air through a ventilated evaporator, pulling heat from the interior and expelling it outside. This continuous cycle maintains an even temperature throughout the cabinet, preventing hot spots that could spoil food. The insulation layer slows heat transfer from the kitchen, reducing the energy needed to hold the set temperature. The operator loads GN 1/1 gastronorm containers onto the wire shelves behind each door. The digital touch control panel is set to the desired temperature between -2 °C and +8 °C. Once the unit reaches the target, the fan-driven cooling system runs automatically, adjusting its output to match the kitchen's ambient conditions. An automatic defrost cycle melts any ice build-up on the evaporator, and the condensate is evaporated by a heating element, eliminating the need for a drain connection. The worktop remains clear for food preparation while the refrigerated section keeps ingredients within reach. The cabinet is constructed from stainless steel, including the exterior, interior, and worktop. A 50 mm insulation layer separates the refrigerated compartment from the outer shell. The technical compartment, housing the compressor and condenser, can be positioned on either the right or left side to fit the kitchen layout. Each door is fitted with a GN 1/1 shelf, and the unit is prearranged for plinth installation if required. The 230 V single-phase supply plugs into a standard UK commercial circuit, allowing installation without dedicated wiring. The 0.405 kW power rating reflects the energy used to maintain temperature over a 24-hour period, balancing cooling performance with operational cost. The 148 kg weight ensures stability on the floor while still allowing repositioning with a pallet truck. The 1760 mm width accommodates two GN 1/1 containers side by side, making efficient use of the 271 L capacity. The seamless stainless-steel surfaces shed grease and spills effortlessly, letting you wipe down the worktop and doors between service rushes without scrubbing or residue. The wire shelves can be removed for thorough cleaning, and the automatic defrost system reduces manual maintenance. The R290 refrigerant is environmentally friendly and complies with current regulations. The TG7D/170 A meets Climate Class 5, ensuring reliable operation in environments up to +40 °C, such as busy commercial kitchens. Energy efficiency class B indicates a balance between performance and energy consumption. The unit is designed for GN 1/1 containers, with customisable drawer configurations available upon request. This refrigerated table is categorised under professional refrigeration for food storage and preparation surfaces.
