Angle screw connection SCHAERER Spare Parts 3322995000

This angle screw connection allows fluid lines to turn at a right angle without bending or narrowing the pipe. The threaded end fits directly into the machine's port, forming a tight seal that resists the pressure of hot water and steam. Its angled shape lets pipes leave the machine body sideways, reducing the space needed behind counters and keeping installations neat beneath cabinets and appliances.

To install, wrap the male thread with PTFE tape to stop leaks. Screw the fitting into the matching female port on the espresso machine by hand until snug. Use a spanner to tighten it fully, positioning the angle to guide the pipe in the correct direction. Attach the pipe to the open end of the connection to finish the water or steam line.

The G1/8" thread follows a standard British pipe size used in professional espresso equipment. It creates a reliable, leak-free joint that can be taken apart and reassembled multiple times without harming the threads. The angled design lets the fitting be turned to fit different pipe arrangements, making it suitable for various machine setups.

Made by SCHAERER for their professional espresso machines, this spare part replaces worn or damaged original connections, helping to preserve the machine's performance and safety.
